9M723 Iskander-M

Maker	KBM, Kolomna (design); Votkinsk Plant (missile production)
Origin	Russia
Built	Votkinsk Plant, Votkinsk, Udmurtia
First combat	2008, Georgia
Length	7.3 m
Diameter	0.92 m
Launch weight	3,800 kg
Warhead	480 kg
Top speed	9,360 km/h
Max range	500 km
Propulsion	Single-stage solid-propellant rocket motor
Guidance	Inertial with GLONASS satellite updates and optional optical terminal seeker

CSIS gives 400 to 500 km range and a 480 to 700 kg warhead; Ukrainian intelligence lists 390 km (550 km for the 9M723-2), a 450 kg warhead, 7.185 m length and 20 to 30 m CEP. Maximum speed is GUR's 2,600 m/s at the start of the terminal phase, converted to km/h; speed at burnout is 2,100 m/s (about 7,560 km/h). A cruise speed does not apply to a ballistic missile.

Sources (11)

1. CSIS Missile Threat: 9K720 Iskander (SS-26) (length_m)
2. CSIS Missile Threat: Iskander (diameter_m)
3. CSIS Missile Threat: Iskander (3,800 to 4,020 kg) (launch_weight_kg)
4. CSIS Missile Threat: Iskander (480 to 700 kg) (warhead_kg)
5. CSIS Missile Threat: Iskander (400 to 500 km) (range_km)
6. CSIS Missile Threat: Iskander (propulsion)
7. CSIS Missile Threat: Iskander (guidance)
8. CSIS Missile Threat: Iskander (Georgia 2008) (first_combat)
9. GUR War & Sanctions: Ballistic missile 9M723 Iskander-M (speed_kmh_max)
10. GUR War & Sanctions: 9M723 Iskander-M specifications (notes)
11. Wikipedia: 9K720 Iskander (Votkinsk Plant; KBM Kolomna) (built_where)
